Lord of the Rings - Sound ROM OS 8 - SERVICE BULLETIN 157 (SETERN)

This update is versions (O/S 4 through O/S 7). only required if you have the symptoms or if you are required to swap boards with different O/S Look! Please Read! >> This new version O/S 8 only corrects the COMPATIBILITY ISSUE. Will not improve the sound of a working board with an older operating system, it Solution Reboot your Flash Memory (U8 IC) with a U7 Bootflash EPROM. Our software department has released the new Sound Operating System O/S 8 Version (which is compatible with all White Star CPU/Sound Board II U7 Sound EPROMs). Symptom: No sound or static and noise in place of normal sounds. These symptoms typically occur after swapping sound ROM’s between different model games using different versions of the Operating System (O/S) (see table below). CPU/SND BD II Games Affected Terminator® 3, The Lord of the Rings , Ripley’s Believe It or Not!®, ELVIS®, Harley-Davidson® 3rd Edition and The Sopranos®. Explanation T3 was the first game to start using the new White Star CPU/Sound II Board (SPI Part Number: 520-5300-00). This PC board utilizes new hardware in the sound section. This hardware required a new Operating System (O/S) in software that has been continually improved and updated since T3 . This has created some compatibility issues between the different versions of Operating Systems. One example would be games using sound ROM’s programmed to work with O/S 5 will not work correctly in a board programmed with O/S 4. The version of the O/S can be identified by the number of times LED1 flashes upon power-up (e.g. The LED1 will f l i c k e r then flash 4 times = O/S 4, ... 5 times = O/S 5, etc.). Note: Color dots** are used on the IC in position U8 to also determine O/S Version for boards.
